Framework using Selenium WebDriver, RestAssured, Page Factory Pattern, Docker, and Kubernetes.

Here's a step-by-step guide to creating a robust testing framework that integrates Selenium WebDriver, RestAssured, Page Factory Pattern, Docker, and Kubernetes.

---

1. Framework Structure

Create a Maven-based project with the following structure:

project-root/
│
├── src/main/java/
│   ├── com.framework.base/
│   │   ├── BaseTest.java
│   │   └── DriverFactory.java
│   ├── com.framework.pages/
│   │   ├── LoginPage.java
│   │   └── HomePage.java
│
├── src/test/java/
│   ├── com.framework.tests/
│   │   ├── ApiTests.java
│   │   └── UITests.java
│
├── src/test/resources/
│   ├── application.properties
│
├── Dockerfile
├── docker-compose.yaml
├── pom.xml
├── README.md

---

2. Maven Dependencies

Add these dependencies to your pom.xml:

<dependencies>
    <!-- Selenium WebDriver -->
    <dependency>
        <groupId>org.seleniumhq.selenium</groupId>
        <artifactId>selenium-java</artifactId>
        <version>4.x.x</version>
    </dependency>

    <!-- RestAssured -->
    <dependency>
        <groupId>io.rest-assured</groupId>
        <artifactId>rest-assured</artifactId>
        <version>5.x.x</version>
        <scope>test</scope>
    </dependency>

    <!-- TestNG -->
    <dependency>
        <groupId>org.testng</groupId>
        <artifactId>testng</artifactId>
        <version>7.x.x</version>
        <scope>test</scope>
    </dependency>

    <!-- Jackson for JSON Parsing -->
    <dependency>
        <groupId>com.fasterxml.jackson.core</groupId>
        <artifactId>jackson-databind</artifactId>
        <version>2.x.x</version>
    </dependency>
</dependencies>

---

3. Framework Components

DriverFactory.java (Selenium WebDriver Setup)

package com.framework.base;

import org.openqa.selenium.WebDriver;
import org.openqa.selenium.chrome.ChromeDriver;
import org.openqa.selenium.chrome.ChromeOptions;

public class DriverFactory {
    private static ThreadLocal<WebDriver> driver = new ThreadLocal<>();

    public static WebDriver getDriver() {
        if (driver.get() == null) {
            ChromeOptions options = new ChromeOptions();
            options.addArguments("--headless", "--no-sandbox", "--disable-dev-shm-usage");
            System.setProperty("webdriver.chrome.driver", "/path/to/chromedriver");
            driver.set(new ChromeDriver(options));
        }
        return driver.get();
    }

    public static void quitDriver() {
        if (driver.get() != null) {
            driver.get().quit();
            driver.remove();
        }
    }
}

---

BaseTest.java (Test Setup)

package com.framework.base;

import io.restassured.RestAssured;
import org.openqa.selenium.WebDriver;
import org.testng.annotations.AfterClass;
import org.testng.annotations.BeforeClass;

public class BaseTest {
    protected WebDriver driver;

    @BeforeClass
    public void setup() {
        driver = DriverFactory.getDriver();
        RestAssured.baseURI = "http://localhost:8080";
    }

    @AfterClass
    public void tearDown() {
        DriverFactory.quitDriver();
    }
}

---

Page Object Classes

LoginPage.java

package com.framework.pages;

import org.openqa.selenium.WebDriver;
import org.openqa.selenium.WebElement;
import org.openqa.selenium.support.FindBy;
import org.openqa.selenium.support.PageFactory;

public class LoginPage {
    WebDriver driver;

    @FindBy(id = "username")
    WebElement usernameField;

    @FindBy(id = "password")
    WebElement passwordField;

    @FindBy(id = "loginButton")
    WebElement loginButton;

    public LoginPage(WebDriver driver) {
        this.driver = driver;
        PageFactory.initElements(driver, this);
    }

    public void login(String username, String password) {
        usernameField.sendKeys(username);
        passwordField.sendKeys(password);
        loginButton.click();
    }
}

---

UITests.java

package com.framework.tests;

import com.framework.base.BaseTest;
import com.framework.pages.LoginPage;
import org.testng.annotations.Test;

public class UITests extends BaseTest {
    @Test
    public void testLogin() {
        driver.get("http://localhost:8080");
        LoginPage loginPage = new LoginPage(driver);
        loginPage.login("admin", "password");
    }
}

---

ApiTests.java

package com.framework.tests;

import io.restassured.RestAssured;
import org.testng.annotations.Test;

import static io.restassured.RestAssured.given;
import static org.hamcrest.Matchers.equalTo;

public class ApiTests {
    @Test
    public void testGetApi() {
        given()
            .when()
            .get("/api/resource")
            .then()
            .statusCode(200)
            .body("message", equalTo("Success"));
    }
}

---

4. Docker Integration

Dockerfile

FROM maven:3.8.4-openjdk-17 AS builder
WORKDIR /app
COPY . .
RUN mvn clean install -DskipTests

FROM openjdk:17-jdk-slim
WORKDIR /app
COPY --from=builder /app/target/*.jar app.jar
ENTRYPOINT ["java", "-jar", "app.jar"]

docker-compose.yaml

version: "3.9"
services:
  app:
    build: .
    ports:
      - "8080:8080"
  selenium-hub:
    image: selenium/hub:4.1.0
    ports:
      - "4444:4444"
  chrome:
    image: selenium/node-chrome:4.1.0
    environment:
      - SE_EVENT_BUS_HOST=selenium-hub
      - SE_EVENT_BUS_PUBLISH_PORT=4442
      - SE_EVENT_BUS_SUBSCRIBE_PORT=4443
    depends_on:
      - selenium-hub

---

5. Kubernetes Integration

Deployment.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: testing-framework
spec:
  replicas: 1
  selector:
    matchLabels:
      app: testing-framework
  template:
    metadata:
      labels:
        app: testing-framework
    spec:
      containers:
      - name: app
        image: your-dockerhub-user/testing-framework:latest
        ports:
        - containerPort: 8080

Service.yaml

apiVersion: v1
kind: Service
metadata:
  name: testing-framework-service
spec:
  type: NodePort
  selector:
    app: testing-framework
  ports:
    - protocol: TCP
      port: 8080
      targetPort: 8080
      nodePort: 30001

---

6. CI/CD Pipeline

• Use Jenkins/GitHub Actions to:
  1. Run tests (mvn test).
  2. Build Docker image (docker build).
  3. Push to Docker Hub.
  4. Deploy to Kubernetes (kubectl apply).

---

This framework combines automation testing with REST API validation, UI testing, and container orchestration to ensure seamless development and deployment.
